| Place of Origin: | Guangdong, China(Mainland) |
|---|---|
| نام تجاری: | OPTFOCUS |
| گواهی: | CE |
| Model Number: | OFS-SF1T4 |
| Minimum Order Quantity: | 2 pieces |
| قیمت: | negotiated |
| Packaging Details: | 125 × 27 × 85 mm |
| Delivery Time: | 3-5 Working Days after Payment Received |
| Payment Terms: | T/T, L/C, Western Union, Paypal |
| Supply Ability: | 10000 Pieces per Month |
| قدرت: | خارجی | حالت نوری: | تک یا دوتایی |
|---|---|---|---|
| دمای محیط: | 0 تا 50+ | حافظه بافر فریم: | 1 مگابایت |
| ابعاد: | 125 × 27 × 85 میلی متر | دمای ذخیره سازی: | -20 ℃ +70 ℃ |
| نوع فیبر: | Mulyimode از Singlemode | ||
| برجسته: | poe network switch,ethernet switch poe,ethernet switch poe |
||
1310nm Managed Power Over Ethernet POE 20KM / Single Mode Fiber Switch 8 Port Poe Gigabit
Main features
With one fiber and four UTP ports, OFS-SF1T4 can convert Optical－Electric Ethernet signals between 10/100MUTP interface (TX) and 100M optical fiber interface (FX).
Auto negotiation function allows UTP port to auto select 10M or 100M, and Full Duplex or Half Duplex.
Support Flow control and Broadcast storm protection
Supporting the max 1536 bytes frame
Internal Circuit of prevented thunder could greatly reduce damage of the converter caused by thunderbolt induction.
Fiber Optic Information
|
Type |
connector |
Fiber type |
Max distance |
Wavelength |
TX power |
Sensitivity |
Link Budget |
|
OFS-SF1T4M |
SC |
multimode |
2km |
850 or 1310nm |
-20～-12dBm |
-30dBm |
10dBm |
|
OFS-SF1T4S |
SC |
singlemode |
20km |
1310nm |
-14～-8dBm |
-32dBm |
18dBm |
5 ports Ethernet Optical Fiber Switch
OFS-SF1T4 Series provides one 100M optical fiber ports and two 10/100M UTP ports. The product is possessed of stable performance, excellent quality and reasonable price because of adopting latest IC from USA and high quality of transceivers. it is applicable to use in small patterns of Optical Fiber Ethernet.
Fiber Optic Information
|
Model |
Product description |
|
OFS-SF1T4M |
10/100M Ethernet Dual Fiber Switch with 4 UTP ports and 1 multimode fiber port, 850 or 1310nm of optical wavelength, the max distance of fiber up to 2km. |
|
OFS-SF1T4S |
10/100M Ethernet Dual Fiber Switch with 4 UTP ports and 1 singlemode fiber port, 1310 or 1550nm of optical wavelength, the max distance of fiber up to 20～100km. |
|
OFS-SF1T4WS |
10/100M Ethernet Single Fiber Switch with 4 UTP ports and 1 singlemode fiber port, 1310/1550nm of optical wavelength, the max distance of fiber up to 20～100km. |
Technical Specifications
| Operating standards | IEEE802.3u 100Base-TX and 100Base-FX |
| Connector |
UTP: RJ-45,10/100Mbps; Fiber: SC/FC,100Mbps (Full Duplex) |
| Cable |
UTP cable: Cat. 5 (the max distance up to 100m) Fiber (multimode): 50/125, 62.5/125μm(the max distance up to 2km) Fiber (singlemode): 8/125, 8.7/125, 9/125, 10/125μm (the max distance up to 100km) |
| Flow control |
Full Duplex: IEEE802.3x flow control Half Duplex: bake pressure flow control |
| LED Light |
PWR, FX Link/Act, TP1 FDX,TP1 Link/Act, TP2 FDX, TP2 Link/Act |
| Power supply | AC100 ～ 240V, DC5V 1A |
| Environment temperature | 0 ～ +50C |
| Storage temperature | -20 ～ +70C |
| Humidity | 5% ～ 90% |
| Dimensions | 125 × 27 × 85mm |
